INCONEL 617 (UNS N06617/W.Nr. 2.4663a) is a solid-solution, strengthened, nickel-chromium-cobalt-molybdenum alloy with an exceptional combination of high-temperature strength and oxidation resistance.
The alloy also has excellent resistance to a wide range of corrosive environments, and it is readily formed and welded by conventional techniques.
The combination of high strength and oxidation resistance at temperatures over 1800°F (980°C) makes INCONEL 617 an attractive material for such components as ducting, combustion cans, and transition liners in both aircraft and land-based gas turbines.
Because of its resistance to high-temperature corrosion, the alloy is used for catalyst-grid supports in the production of nitric acid, for heat-treating baskets, and for reduction boats in the refining of molybdenum.
INCONEL alloy 617 also offers attractive properties for components of power-generating plants, both fossilfueled and nuclear.
Chemical composition
Nickel...........................................................................44.5 min.
Chromium....................................................................20.0-24.0
Cobalt..........................................................................10.0-15.0
Molybdenum .................................................................8.0-10.0
Aluminum ........................................................................0.8-1.5
Carbon ........................................................................0.05-0.15
Iron................................................................................3.0 max.
Manganese ...................................................................1.0 max.
Silicon ...........................................................................1.0 max.
Sulfur ........................................................................0.015 max.
Titanium ........................................................................0.6 max.
Copper..........................................................................0.5 max.
Boron ........................................................................0.006 max.
Physicail properties
Density, lb/in3 .....................................................................0.302
Mg/m3 ....................................................................8.36
Melting Range, °F .....................................................2430-2510
°C .....................................................1332-1380
Specific Heat at 78°F (26°C)
Btu/lb-°F..................................................0.100
J/kg-°C.......................................................419
Electrical Resistivity at 78°F (26°C)
ohm-circ mil/ft............................................736
µΩ-m .........................................................1.22
Specs referred
Rod, Bar, Wire, and Forging Stock
ASTM B 166/ASME SB 166 (Rod, Bar and Wire)
ASTM B 564/ASME SB 564 (Forgings)
SAE AMS 5887 (Bars, Forgings and Rings)
VdTÜV 485 (Sheet, Plate, Bar and Tubing),
ISO 9724 (Wire)
DIN 17752 (Rod and Bar)
DIN 17753 (Wire),
DIN 17754 (Forgings)
Plate, Sheet, and Strip
ASTM B 168/ASME SB 168 (Plate, Sheet and Strip)
SAE AMS 5888 (Plate)
SAE AMS 5889 (Sheet and Strip)
VdTÜV 485 (Sheet, Plate, Bar and Tubing)
ISO 6208 (Plate, Sheet and Strip)
DIN 17750 (Plate, Sheet and Strip)
Pipe and Tube
VdTÜV 485 (Sheet, Plate, Bar, and Tubing)
ISO 6207 (Tubing)
ASTM B 546/ASME SB 546 (Pipe)
DIN 17751 (Pipe and Tube)
Composition - DIN 17744
Welding Products
INCONEL Filler Metal 617 - AWS A5.14/ERNiCrCoMo-1;
INCONEL Welding Electrode 117- AWS A5.11 / ENiCrCoMo-1
