Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing

Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing

    • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing
    • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing
    • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing
    • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing
    • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing
    • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing
    • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing
  • Hastelloy C276 UNS N10276 W.Nr.2.4819 alloy plate, strip, wire, bar, forging, pipe, tubing

    Product Details:

    Place of Origin: Suzhou, China
    Brand Name: XUNSHI
    Certification: ISO9001:2015
    Model Number: UNS N10276

    Payment & Shipping Terms:

    Minimum Order Quantity: 10kg
    Price: Contac Xunshi to confirm
    Packaging Details: By customers' require
    Delivery Time: 20 days
    Payment Terms: 30% T/T in advance, balance before shipment
    Supply Ability: 10000 kg per month
    Contact Now
    Detailed Product Description
    Equal Grades: N10276, Hastelloy C276, Alloy 276, NS334,00Cr16Ni60Mo16W4,W.Nr.2.4819, NC17D Spec: ASTM B 462
    Form Of Supply: Forging, Rod, Wire, Pipe, Tubing, Fitting, Capillary

    Hastelloy C276 (UNS N10276) NS334,00Cr16Ni60Mo16W4,UNS N10276,W.Nr.2.4819, NC17D

    Introduction

    A-one Alloy  supplies Hastelloy C276 bars from ex-stock. And we keep regular stock for  Hastelloy sheet/plate from EU/US/Japan. We have plenty of Hastelloy C276  ingot in our warehouse which enable us to make fast delivery.

    Hastelloy C276 is a  nickel-molybdenum-chromium superalloy with an addition of tungsten designed  to have excellent corrosion resistance in a wide range of severe  environments. The high nickel and molybdenum contents make the nickel steel  alloy especially resistant to pitting and crevice corrosion in reducing  environments while chromium conveys resistance to oxidizing media. The low  carbon content minimizes carbide precipitation during welding to maintain  corrosion resistance in as-welded structures. This nickel alloy is resistant  to the formation of grain boundary precipitates in the weld heat-affected  zone, thus making it suitable for most chemical process application in an as  welded condition.

    Although there are several variations  of the Hastelloy nickel alloy, Hastelloy C-276 is by far the most widely  used.

    Hastelloy C-276 is widely used in the  most severe environments such as chemical processing, pollution control, pulp  and paper production, industrial and municipal waste treatment, and recovery  of sour natural gas.

    Characters

    • Excellent corrosion resistance in reducing environments
    • Exceptional resistance to strong solutions of oxidizing  salts, such as ferric and cupric chlorides
    • High nickel and molybdenum contents providing good  corrosion resistance in reducing environments
    • Low carbon content which minimizes grain-boundary  carbide precipitation during welding to maintain resistance to corrosion in  heat-affected zones of welded joints
    • Resistance to localized corrosion such as pitting and  stress-corrosion cracking
    • One of few materials to withstand the corrosive effects  of wet chlorine gas, hypochlorite and chlorine dioxide

    Application

    • Pollution control stack liners, ducts, dampers,  scrubbers, stack-gas reheaters, fans and fan housings
    • Flue gas desulfurization systems
    • Chemical processing components like heat exchangers,  reaction vessels, evaporators, and transfer piping
    • Sour gas wells
    • Pulp and paper production
    • Waste treatment
    • Pharmaceutical and food processing equipment

    Equal grades

    NS334,00Cr16Ni60Mo16W4,UNS N10276,W.Nr.2.4819, NC17D

    Chemical  composition

    Nickel...................................................Balance

    Molybdenum........................................15.0-17.0

    Chromium............................................14.5-16.5

    Iron  .....................................................4.0-7.0

    Tungsten.............................................3.0-4.5

    Cobalt  .................................................2.5 max.

    Manganese  .........................................1.0 max.

    Carbon.................................................0.01  max.

    Vanadium............................................0.35  max.

    Phosphorus  ........................................0.04 max.

    Sulfur  ..................................................0.03 max.

    Silicon  .................................................0.08 max.

    Standards

    Rod, Bar, Wire  and Forging Stock - ASTM B 462 (Rod, Bar and Forging Stock), ASTM B 564  & ASME SB 564 (Forgings), ASTM B 574 & ASME SB 574 (Rod, Bar and Wire),

    Plate, Sheet and  Strip - ASTM B 575/B  906 & ASME SB 575/SB 906

    Pipe and Tube - ASTM B 622/B 829 & ASME SB  622/SB 829 (Seamless Tube), ASTM B 626/B 751 & ASME SB 626/SB 751 (Welded  Tube), ASTM B 619/B 775 & ASME SB 619/SB 775 (Welded Pipe)

    Others - ASTM B 366 & ASME SB 366  (Fittings)

    Forms available

    Plate, sheet, strip, wire, rod, bar,  forging, tube, pipe, pipe fitting, ring, disc, fastener

    Delivery

    Plenty of bar, plate, sheet in stock. For  orders, delivery of bar and forging is 2 weeks. Delivery of other products  available on request.

    * Hastelloy is the registered trademarkname of Haynes International, Inc.
